The glass used in glass curtain walls should be safety glass, mainly tempered glass, laminated (laminated) glass, insulating glass, fireproof glass, sunlight control coated glass and low-emissivity coated glass (Low-E), etc. The specific selection requirements are as follows:

1. Safety glass should be used for curtain walls, and the thickness of the glass should not be less than 6mm. The thickness of the rib glass of the full glass curtain wall should not be less than 12mm.

2. When the glass curtain wall uses heat-reflective coated glass, vacuum magnetron cathode sputtering coated glass or online thermal spraying coated glass should be used. The appearance quality and technical indicators of float glass used for heat-reflective coated glass should comply with the provisions of superior or first-class products in the current national standard "Float Glass" (GB11614).

3. The insulating glass of the curtain wall should be double-sealed.

The insulating glass of the exposed frame curtain wall should use polysulfide sealant and butyl sealant. The insulating glass of the hidden frame and semi-hidden frame curtain wall should use silicone structural sealant and butyl sealant; the coating surface should be on the second or third surface of the insulating glass.

4. The laminated glass of the curtain wall should be laminated glass synthesized by dry processing of polyvinyl butyral (PVB) film. The thickness of the interlayer film (PVB) of the laminated glass of the point-supported glass curtain wall should not be less than 0.76mm.

5. Tempered glass should comply with the provisions of GB9963 "Tempered Glass".

6. All curtain wall glass should be edge-treated.

Regarding the selection of curtain wall glass, let's continue to see what other suggestions are there?

1. Safety glass should be used for frame-supported glass curtain walls

Frame-supported glass curtain walls include two forms: visible frame and hidden frame. They are currently the most widely used in glass curtain wall projects. This provision is for the safety of curtain wall glass during installation and use.

Safety glass generally refers to tempered glass and laminated glass.

The inclined glass curtain wall refers to a curtain wall with an angle of less than 90 degrees and greater than 75 degrees with the horizontal plane. The particles after the glass is broken will also affect safety. Laminated glass is non-scattering glass, which can protect people and other people, and should be used first.

2. Tempered glass should be used for the panel glass of point-supported glass curtain walls

The panel glass of point-supported glass curtain walls should be tempered glass and its products, otherwise the strength will not meet the requirements due to stress concentration at the punching position.

3. For point-supported glass curtain walls supported by glass ribs, the glass ribs should be tempered laminated glass

For point-supported glass curtain walls supported by glass ribs, the rib glass is a supporting structure, and the stress concentration at the punching point is obvious, so the strength requirement is high; on the other hand, if the glass ribs are broken, the entire curtain wall will collapse. Therefore, tempered laminated glass should be used.

4. Other public places

Obvious warning signs should be set up in public places with high population density, activities of teenagers or young children, and parts that are easily hit during use. Glass curtain walls in public places with high population density and activities of teenagers or young children are prone to being squeezed and hit; in other buildings, parts of the curtain walls that may be hit during normal activities are also prone to glass damage. To ensure personnel safety, safety glass should be used for glass curtain walls in these cases. Obvious warning signs should also be set up for glass curtain walls that are easily hit to avoid harm caused by accidental collisions.

5. When there is no solid wall on the outer edge of the floor adjacent to the glass curtain wall, anti-collision facilities should be set up.
